Now, we have new special sale lcd panels " Stretched LCD Panel"
So . If you need the more informs about it, please contact us.
We can supply you Stretched lcd panel with very high quality and Competitive price. ( All size )
If you have interested of our suggest, pelase contact us.
For your reference, We inform you our specification for 42inch Stretched lcd panel ( 1920 x 540 )
Please check it,
If you have any questions, please contact us anytime.
We will do our best to serve you.
- Special Offer for 42inch Stretched LCD Panel.
Model No : ST4238ML-L1
MOQ: 100pcs , lead time : about 4-5weeks after your payment to our Bank.
The ST4238ML-L1 is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED)
back l light system. The matrix employs a-Si Thin Film Transistor as the active element .
It is a transmissive display type which is operating in the normally black mode. It has a 38 inch diagonally
measured active display area with WUXGA resolution (540 vertical by 1920 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.06Bilion colors.
It has been designed to apply the 10-bit 2-port LVDS interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
|
Active Display Size |
930.24 mm(H) x 261.63 mm(V) |
|
Display format |
42inch, 1 / 2 type |
|
Outline Dimension |
973.2 mm(H) x 304.6 mm(V) x 30 mm(D) |
|
Pixel Pitch |
0.4845 mm x 0.4845 mm |
|
Pixel Format |
1920 horiz. by 540 vert. pixels RGB stripe arrangement |
|
Interface |
LVDS 4Port |
|
Color Depth |
10Bit(D) , 1.06 Billion colors |
|
Luminance, White |
500 cd/m2 (Center 1-point) (Typ.) |
|
Viewing Angle (CR>10) |
Viewing Angle Free ( R/L 178 (Typ.), U/D 178 (Typ)) |
|
Power Consumption |
Total 75W (Typ.) (Logic=10W, LED Driver=65W) |
|
Weight |
7.0 Kg (Typ) |
|
Display Operating Mode |
Transmissive mode, Normally black |
|
Surface Treatment |
Hard coating (3H),
Anti-glare treatment of the front polarizer (Haze 10%) |
